Insect screen
insect-screen for Window and Door.
Share
FBA
Technical parameter
Application
Package
Features and benefits:
 |
*Constructed with ultra-fine wire mesh composed of 304 and 316 stainless steel, copper, or aluminum alloy |
 |
*Precision-engineered fine wire mesh designed to effectively deter insects and contaminants while allowing optimal airflow and natural light.Intricately woven ultra-fine mesh effectively bars even the tiniest insects and airborne particles, while offering crystal-clear clarity. |
 |
*Enhanced Security&Unparalleled Clarity: Experience a shield against insects and pests, ensuring a pest-free and serene living environment. Revel in unobstructed outdoor views through the fine and ultra-fine wire mesh that offers remarkable transparency. |
 |
*Purify Indoor Air : The fine & ultra-fine mesh acts as a barrier to pollen, allergens, and minuscule contaminants, ensuring a pristine indoor atmosphere |
 |
*Unhindered Views: Enjoy unrestricted views of the outdoors while keeping your space well-ventilated and illuminated.Experience the comfort of natural ventilation and abundant daylight without compromising on protection. Advantage:Excellence in Craftsmanship & Cutting-Edge Elegance |
 |
*Super rust prevention: The fine & Ultra-fine metal window screens stands out for their exceptional rust and corrosion resistance. With their meticulously crafted grid structure and high-quality metal materials such as stainless steel 304 and 316, aluminum alloy, they possess enduring qualities. Not only do they effectively prevent metal materials from oxidizing due to moisture, but they also maintain their quality in adverse weather conditions. This makes ultra-fine metal window screens an ideal choice for outdoor use, providing long-term and stable protection for indoor environments. |
 |
*Ultimate Precision: Crafted with the utmost precision using advanced weaving techniques, resulting in a product of exceptional quality. |
 |
*Sophisticated Design: The fine & ultra-fine wire mesh provides security and clarity while adding an element of sophistication to your living spaces.The seamless integration of the fine wire mesh with your windows enhances your space's visual appeal. |
 |
*Distinguished BAL grade: The fine & Ultra-fine metal window screens hold significant advantages in Australia's BAL (Bushfire Attack Level) standards. Their high-quality metal materials, such as stainless steel 304 and 316, aluminum alloy, impart exceptional heat resistance and fire-retardant properties to the screens. In high-risk fire-prone areas, ultra-fine metal window screens effectively block embers and burning debris, ensuring indoor safety. Their intricate weave structure also aids in reducing the risk of fire propagation, making ultra-fine metal window screens an ideal choice for bushfire prevention in Australia. |
| KY110H wire composition | 304 Stainless steel screen |
| Mesh | 24x22 |
| Wire Diameter | 0.11mm |
| Aperture | 0.92x1.01mm |
| Openness | 82% |
| Light transmittance | 99% |
| Weight | 120g/m2 |
| Tensile Strength | 1555Mpa |
| Elongation | 2% |
| Color | Black (other colors need to be customized) |
| Width | Customized and Maximum width is 2.8 meters |
| Roll Length | Customized and Maximum length is 1000 meters |
| Packing | Cardboard Tube + Wooden Case |
| Suggested Applications | Roll up screen, Fireplace, Filtration Industry |
| KYS130 wire composition | 304 Stainless steel screen |
| Mesh | 24x22 |
| Wire Diameter | 0.13mm |
| Aperture | 0.92x1.01mm |
| Openness | 80% |
| Light transmittance | 98% |
| Weight | 210g/m2 |
| Tensile Strength | 750N/mm2 |
| Elongation | 35% |
| Color | Black (other colors need to be customized) |
| Width | Customized and Maximum width is 2.8 meters |
| Roll Length | Customized and Maximum length is 1000 meters |
| Packing | Cardboard Tube + Wooden Case |
| Suggested Applications | Window Screen, Filtration Industry |
| KYS150 wire composition | 304 Stainless steel screen |
| Mesh | 18x18 |
| Wire Diameter | 0.15mm |
| Aperture | 1.25x1.25mm |
| Openness | 80% |
| Light transmittance | 98% |
| Weight | 210g/m2 |
| Tensile Strength | 750N/mm2 |
| Elongation | 35% |
| Color | Black (other colors need to be customized) |
| Width | Customized and Maximum width is 2.8 meters |
| Roll Length | Customized and Maximum length is 1000 meters |
| Packing | Cardboard Tube + Wooden Case |
| Suggested Applications | Window Screen, Filtration Industry |
| KYS140H wire composition | 304 Stainless steel screen |
| Mesh | 18x18 |
| Wire Diameter | 0.14mm |
| Aperture | 1.25x1.25mm |
| Openness | 82% |
| Light transmittance | 95% |
| Weight | 190g/m2 |
| Tensile Strength | 1555N/mm2 |
| Elongation | 2% |
| Color | Black (other colors need to be customized) |
| Width | Customized and Maximum width is 2.8 meters |
| Roll Length | Customized and Maximum length is 1000 meters |
| Packing | Cardboard Tube + Wooden Case |
| Suggested Applications | Roll up screen, Filtration Industry |
| KYSS200 wire composition | 316 Stainless steel screen |
| Mesh | 18x16 |
| Wire Diameter | 0.20mm |
| Aperture | 1.21x1.38mm |
| Openness | 75% |
| Weight | 310g/m2 |
| Tensile Strength | 750N/mm2 |
| Elongation | 35% |
| Color | Black (other colors need to be customized) |
| Width | Customized and Maximum width is 2.8 meters |
| Roll Length | Customized and Maximum length is 1000 meters |
| Packing | Cardboard Tube + Wooden Case |
| Suggested Applications | Window Screen, Door Screen, Filtration Industry |
| KYS300 wire composition | 304 Stainless steel screen |
| Mesh | 16x16 |
| Wire Diameter | 0.30mm |
| Aperture | 1.28x1.28mm |
| Openness | 65% |
| Weight | 670g/m2 |
| Tensile Strength | 750N/mm2 |
| Elongation | 35% |
| Color | Black (other colors need to be customized) |
| Width | Customized and Maximum width is 2.5 meters |
| Roll Length | Customized and Maximum length is 500 meters |
| Packing | Cardboard Tube + Wooden Case |
| Suggested Applications | Window Screen, Door Screen, Filtration Industry |
| KYS600 wire composition | 304 Stainless steel screen |
| Mesh | 12x12 |
| Wire Diameter | 0.60mm |
| Aperture | 1.50x1.50mm |
| Openness | 50% |
| Weight | 2160g/m2 |
| Tensile Strength | 750N/mm2 |
| Elongation | 35% |
| Color | Black (other colors need to be customized) |
| Width | Customized and Maximum width is 1.6meters |
| Roll Length | Customized and Maximum length is 50 meters |
| Packing | Cardboard box + Wooden Case |
| Suggested Applications | Window Screen, Door Screen, Filtration Industry |
| KYC240 Wire Composition | Copper Alloy |
| Mesh | 18x14 |
| Wire Diameter | 0.24mm |
| Aperture | 1.16x1.56mm |
| Openness | 71% |
| Weight | 500g/m2 |
| Tensile Strength | 600N/mm2 |
| Elongation | 1% |
| Color | Golden color |
| Width | Customized and Maximum width is 2.5meters |
| Roll Length | Customized and Maximum length is 500 meters |
| Packing | Cardboard box + Wooden Case |
| Suggested Applications | Window Screen, Door Screen, Filtration Industry |
| KYL250 Wire Composition | Aluminum Alloy 5154 |
| Mesh | 18x16 |
| Wire Diameter | 0.25mm |
| Aperture | 1.15x1.33mm |
| Openness | 68% |
| Weight | 180g/m2 |
| Tensile Strength | 360N/mm2 |
| Elongation | 5% |
| Color | Black (other colors need to be customized) |
| Width | Customized and Maximum width is 2.8 meters |
| Roll Length | Customized and Maximum width is 1000 meters |
| Packing | Cardboard box + Wooden Case |
| Suggested Applications | Window Screen, Door Screen, Filtration Industry |
| KYT250 Wire Composition | Galvanized Iron Wire |
| Mesh | 12x12 |
| Wire Diameter | 0.25mm |
| Aperture | 1.86x1.86mm |
| Openness | 77% |
| Weight | 400g/m2 |
| Tensile Strength | 1050N/mm2 |
| Elongation | 1% |
| Color | Black (other colors need to be customized) |
| Width | Customized and Maximum width is 2.5 meters |
| Roll Length | Customized and Maximum width is 1000 meters |
| Packing | Cardboard box + Wooden Case |
| Suggested Applications | Window Screen, Door Screen, Filtration Industry |
| KYT150H Wire Composition | Galvanized Iron Wire |
| Mesh | 18x18 |
| Wire Diameter | 0.15mm |
| Aperture | 1.22x1.22mm |
| Openness | 80% |
| Weight | 200g/m2 |
| Tensile Strength | 1050N/mm2 |
| Elongation | 1% |
| Color | Black (other colors need to be customized) |
| Width | Customized and Maximum width is 2.8 meters |
| Roll Length | Customized and Maximum width is 1000 meters |
| Packing | Cardboard box + Wooden Case |
| Suggested Applications | Window Screen, Door Screen, Filtration Industry |
| KYF280 Yarn Composition | Galvanized Iron Wire |
| Mesh | 18x16 |
| Wire Diameter | 0.28mm |
| Aperture | 1.13x1.46mm |
| Openness | 63% |
| Weight | 116g/m2 |
| Tensile Strength | 740N/50 mm（warp）590N/50 mm（weft） |
| Elongation | 3% |
| Color | Black/Gray (other colors can be customized) |
| Width | Customized and Maximum width is 3.2 meters |
| Roll Length | Customized and Maximum width is 1000 meters |
| Packing | Cardboard box + Wooden Case |
| Suggested Applications | Retractable Window Screen, Retractable Door Screen |
| KYF260 Wire Composition | 34% Fiberglass + 66% PVC |
| Mesh | 18x18 |
| Wire Diameter | 0.26mm |
| Aperture | 1.15x1.49mm |
| Openness | 68% |
| Weight | 78g/m2 |
| Tensile Strength | 765N/50 mm（warp）765N/50 mm（weft） |
| Elongation | 3% |
| Color | Black/Gray (other colors can be customized) |
| Width | Customized and Maximum width is 3.2 meters |
| Roll Length | Customized and Maximum width is 1000 meters |
| Packing | Cardboard box + Wooden Case |
| Suggested Applications | Retractable Window Screen, Retractable Door Screen |
 |
 |
 |
 |
|
Outer packing: |
Wooden box |
|
Innerpacking: |
Cardboard Tube + Each roll in individual carton |
